SKU: 872-860-546 Automotive Connector
Category: Automotive Connectors
Availability: 1000
Tag: 872‑860‑546 , hirschmann connector , 5‑way connector , 1.2 sealstar fa , sealed female housing , automotive maf connector , wire-to-wire sensor connector , cpa/tpa locking , ip67 rated , 1.2 mm terminals , mercedes-benz connector , bmw connector , vw connector , engine bay connector , sealed automotive connector , high-temp thermoplastic housing.
Brand: HIRSCHMAN AUTOMOTIVE
Model Number: 872-860-546
Availability: In stock
Product SKU: 872-860-546 Automotive Connector
Minimum order quantity: 50
Maximum order quantity:
Listed date: 24th Jul, 2025
| Attribute | Specification |
|---|---|
| Part Number | 872-860-546 |
| Manufacturer | Hirschmann Automotive |
| Series | 1.2 SealStar FA Series |
| Connector Type | Female Housing |
| Number of Positions | 5 |
| Contact Type | Receptacle (female terminals) |
| Terminal Size | 1.2 mm |
| Mounting Type | In-line (Free Hanging) |
| Locking Mechanism | CPA (Connector Position Assurance) + Primary Locking Latch |
| Sealing | Integrated Silicone Seal (Environmental Sealing, IP67) |
| Wire Size Range | 0.35 mm² – 1.0 mm² |
| Housing Material | High-Temperature Thermoplastic |
| Housing Color | Typically Black (may vary) |
| Operating Voltage | ≤ 60 V DC |
| Operating Temperature | -40°C to +120°C |
| Connector System | Wire-to-Wire |
| Mating Component | 5-way SealStar FA Male Housing |
| Standards Compliance | RoHS Compliant, USCAR-2, ISO/TS 16949 |
| Typical Applications | MAF/MAP sensors, engine harness, automotive ECUs, lighting, and under-hood wiring |
