SKU: TE Connectivity / AMP 1-965640-1
Category: Automotive Connectors
Availability: 10000
Tag: 1-965640-1 , te connectivity , amp mcp 2.8k , sealed plug housing , automotive connector , wire-to-wire , cpa lock , crimp contact , high current connector , te amp , high temperature housing , black plug , mcp connector series , vehicle wiring
Brand: TE Connectivity
Model Number: 1-965640-1
Availability: In stock
Product SKU: TE Connectivity / AMP 1-965640-1
Minimum order quantity: 50
Maximum order quantity:
Listed date: 24th Jul, 2025
| Attribute | Specification |
|---|---|
| Part Number | 1-965640-1 |
| Manufacturer | TE Connectivity |
| Series | AMP MCP 2.8K |
| Connector Type | Plug Housing |
| Number of Positions | 6 |
| Connector System | Wire-to-Wire |
| Contact Type | Receptacle (Female) |
| Sealing | Yes (Sealed) |
| Primary Locking Feature | Integrated |
| Secondary Locking Feature | CPA (Connector Position Assurance) |
| Mounting Type | Free Hanging (In-Line) |
| Mating Part | 1-965641-1 (Cap Housing) |
| Housing Material | High-temperature Thermoplastic |
| Housing Color | Black |
| Wire Size Range | 0.5 – 2.5 mm² |
| Operating Temperature | -40°C to +125°C |
| Contact Insertion Style | Crimp |
| Row Configuration | Single Row |
| Application | Automotive, Commercial Vehicles |
