SKU: TE Connectivity 8-968973-1
Category: Automotive Connectors
Availability: 1000
Tag: 8-968973-1 , te connectivity , amp mcp 2.8k , 15 position connector , cap housing , sealed connector , wire-to-wire , cpa lock , high current connector , automotive connector , crimp terminal , high temperature housing , te amp , black housing , mcp 2.8 series , vehicle wiring connector
8-968973-1 is a 15-position cap housing from TE Connectivity’s AMP MCP 2.8K series, built for sealed automotive wire-to-wire applications. This cap housing provides a secure and environmentally resistant interface when mated with a corresponding plug housing. It supports high-current MCP 2.8 contacts, features robust primary and CPA secondary locking mechanisms, and is suitable for applications in harsh vehicle environments, including under-hood and chassis systems.
Brand: TE Connectivity
Model Number: 8-968973-1
Availability: In stock
Product SKU: TE Connectivity 8-968973-1
Minimum order quantity: 50
Maximum order quantity:
Listed date: 24th Jul, 2025
| Attribute | Specification |
|---|---|
| Part Number | 8-968973-1 |
| Manufacturer | TE Connectivity |
| Series | AMP MCP 2.8K |
| Connector Type | Cap Housing (Female Connector Housing) |
| Number of Positions | 15 |
| Connector System | Wire-to-Wire |
| Contact Type | Tab (Male terminal interface) |
| Sealing | Yes (Sealed) |
| Primary Locking Feature | Integrated |
| Secondary Locking Feature | CPA (Connector Position Assurance) |
| Mounting Type | Free Hanging (In-Line) |
| Mating Part | 8-968971-1 (Plug Housing) |
| Housing Material | High-temperature Thermoplastic |
| Housing Color | Black |
| Wire Size Range | 0.5 – 2.5 mm² |
| Operating Temperature | -40°C to +125°C |
| Contact Insertion Style | Crimp |
| Application | Automotive, Commercial Vehicles |
| Row Configuration | Single Row |
